Scissor Style (SCI) Top Loading Arm

Primarily used to load tank trucks where the reaches will be less than 120” (3,048 mm). This versatile arm is designed specifically for top-loading installations where a variable operating range is required. The secondary arm rotates 360 degrees in the horizontal plane, providing a spotting allowance of up to twice its length.

The New StandardLine

StandardLine Loading Arms by OPW Engineered Systems raise the bar in quality and performance for the industry. Get OPW's best-in-class loading systems in pre-engineered sizes, materials and feed orientations with delivery in 20 days or less. All StandardLine Loading Arms feature:

  • Fast Delivery - 20 days or less!
  • Menu of Options to Customize Your Arm
  • Included Freight in the Continental US and Canada
  • Exclusive 3-Year Warranty

’20 Days or Less’ refers to 20 working days
