1004D3 API Bottom Loading Coupler

The latest in API Bottom Loading Couplers, a proven performer at major oil terminals around the world.

5-Cam Design: Easy alignment, tight adaptor connections and side-force resistance during loading
Dual Interlocks: Ensure that opening cannot occur unless properly connected to an API Adaptor
Superior Sealing: Simple, reliable smart-seal design with dual high-performance O-rings
High-Performance Seals: Special Fluorocarbon Seal Compound for compatibility across most products, including gasoline, diesel, biodiesel and ethanol*
Maintenance: Pins and small threads eliminated to provide quick, easy access to critical components; nose seal replaced without requiring removal of coupler from rack; no special tools required; complete rebuild in minutes
Operation: Stainless-steel “ergo” handle design for easy, smooth operation

*-Other seals available upon request.

Order Guide

Units (1004D3 & 1005E3)

Seal Kits
OPW 1004D3SRK Seal Replacement Kits include everything needed to change the seals in the 1004D3/1005E3 API Coupler.

Seal Material	Seal Replacement Kit Part #
Buna	1004D3SRK-0401
Fluorocarbon	1004D3SRK-0402
EPT	1004D3SRK-0404

Technical

Click on the title below to view the technical information.

Design Parameters & Materials

Design Parameters	Materials
Max Design Pressure:	125 PSI (g), 8.6 bar (g)	Body, Sleeve, Poppet	ASTM B26 Anodized (Aluminum A356-T6)
Max Allowable Working Pressure:	75 PSI (g), 5 bar (g)	Cam	ASTM A351 CF8M (316 SST)
Max Flow Rate:	600 GPM, 135 M3/H	Cylinder	ASTM SB241 (Aluminum 6061-T6)
Max Temperature:	See Seal Options (page 3)	Shaft	ASTM A564 (13-8 Condition RH 950 SST)
Weight:	18.5 lbs (8.39 kg)	Seals	See Seal Options
Pressure Drop (At Max Flow Rate)	2-5 PSI (g), .24 bar (g)	Clevis Pin	ASTM SA 564 (17-4 PH SST, H900 Hardened)

Seal Options

Seal Material	Coupler Model #	Nose Seal (10)	Stuff Box Seal (22)	Stuff Box Seal (23)	Cylinder Seal (9)	Temp. Rating
Buna	1004D3-0401/1005E3-0401	H30482M	H20129M	H31705M	H30258M	-20°F–250°F (-29°C–121°C)
Fluorocarbon	1004D3-0402/1005E3-0402	H30483M	H20175M	H31706M	H30217M	-20°F–400°F (-29°C–204°C)
EPT	1004D4-0404/1005E3-0404	H31957M	H20176M	H31707M	H31956M	-50°F–225°F (-46°C–107°C)

Parts Breakdown

#	Description	Qty	Material	Part #
1	Body, API Coupler, ALUM, 1004D3	1	Aluminum A356-T6, ASTM B26 Anodized	E20064AH
2	Spirol Pin	7	Carbon Steel Zinc Plated	H31396M
3	Compression Spring	2	Carbon Steel Zinc Plated	H31743M
4	Interlock	2	316 SST, ASTM A351 CF-8M	C20062M
5	Cam Spring	5	18-8 SST	H06753M
6	Cam Arm, 1004 CPLR, SST	5	SST	C20063M
7	Wave Spring	1	Inconel	H31091M
8	Cylinder	1	ASTM SB241 (Aluminum 6061-T6)	C21283AH
9	Cylinder O-Ring	1	Fluorocarbon	C21283AH	*
10	Nose Seal, API CPLR, Fluorocarbon	1	Fluorocarbon	H30483M	*
11	Poppet	1	A356-T6 Aluminum	D20069AH
12	High Pressure Link	2	410 SST Hardened	H30552M
13	Clevis Pin	2	17-4 PH SST	H30610RE
14	Cotter Pin	2	316 SST	H30206M
15	Washer, Flat, SST, 5/16	2	18-8 SST	H30554M
16	Drive Link	1	316 SST	C21255EW
17	Sleeve, API Coupler, AL, 4"	1	Aluminum A356-T6 ASTM B26 Anodized	E20013AH (1004D3) E20026AH (1005E3)
18	Dust Seal	1	Felt	H30214M
19	Tube Spacer, API, SST	1	316 SST.	C21254RE
20	Handle Shaft	1	ASTM A564 (13-8, Condition RH 950 SST)	C21290RE
21	Stuff Box, API and LOK, SSST	1	316 SST	C20812RE
22	O-Ring, Fluorocarbon	2	Fluorocarbon	H20175M	*
23	O-Ring, Fluorocarbon	1	Fluorocarbon	H31706M	*
24	Sleeve Bearing	1	Teflon	H32163M	*
25	Operating Handle	1	316 SST, ASTM, A351 CF-8M	E20070EW
26	Loctite	As Required	Threaded Locking Compound	Type 242
27	Nut, Hex, CST, ZP, 3/8"-24	1	ZP CST	H30220M
28	Washer, Nord-lock, SST, NL 10ss	1	SST	H31920M
29	6-20 X 3/16" Long Thread Screw	4	Steel, Zinc Plated	H32149M
30	Load Distribution Washer	1	410 SST	H32246RE
31	Roller Bearing	1	Carbon Steel	H30219M
32	Distorted Thread Nut, 10mm	1	Steel, Zinc Plated	H32256M
33	Nameplate, 1004D3-0402, Fluorocarbon	1	0.12 Satin	H32157M
*Items included in seal replacement kits (1004D4SRK).

Accessories

API Coupler Drain Sample Adapter (1004DRN-0400)
Safely take samples from any API Coupler

API Coupler Parking Adapter (1004PA-0400)

API Coupler Weather Cap (1004WC-0400)
Protects any API Coupler during inclement weather

API Coupler Drain Adapter (1004DRNFULL-0400)
Safely drain your API Bottom Loading Arm
