OPW 200TG AST Mechanical Tank Gauge

The OPW 200TG Tank Gauge is designed for reading liquid levels in horizontal or vertical aboveground storage tanks. The 200TG Tank Gauge provides an accurate numerical counter readout, eliminating the need for any on-site manual gauging.

200TG AST Mechanical Tank Gauge

Features & Benefits

Materials

Enclosure: Powder-coated aluminum
Swivel Base: Hard-coat aluminum
Float: 304 stainless steel
Lenses: Tempered borosilicate
Gears: Acetal
Gaskets & O-Rings: Nitrile®
All Hardware: Stainless steel
Accuracy: + or - 2"

Features

Vapor Tight - Allows for standard tank pressure testing and sealing up to 25-psig (1.72 bar).
Angled Face - Improves visibility from ground on large diameter tanks. May be easily read up to 30 ft. away (9.14 m).
Swivel Adaptor Base - Allows for 360 degrees of rotation of gauge face for easy viewing wherever needed.
Easy Installation - 2" NPT-threaded base reduces labor time, and comes standard with female thread. A "H11421RS" may be purchased for male thread applications.
Corrosion-Resistant Construction - A powder-coated die cast-aluminum body assures long service life in many fluids.
Drop Tube - Prevents float entanglement in the tank, and gives the gauge a more accurate reading when turbulence is present. (Drop Tubes sold separately. They are recommended for use in tanks with high turbulence, and where other piping and structures inside the tank may cause entanglement.)
Float Buoyancy - Designed to float in all fluids with a specific gravity of 0.65 and greater.
Tank Height - Unit designed for use on any horizontal or vertical aboveground tank up to 18 ft. (5.5 m) in depth. Specials available upon request.
Numbering - Black letters on white background for ultimate contrast and better visibility. Characters stand over 1" (25 mm) tall.
Unit Measurement - Can be purchased in metric units to read in meters, 1/10, 1/100, or in English units to read in feet and inches.
Maintenance - No annual maintenance required.
U.S. Patent No.: 6,523,404 - Other Patents Pending.
Compatible Fuels See chart
Temperature Rating – 120ºF to -40ºF (49ºC to -40ºC)

Listings and Certifications

Underwriters Laboratory Listed - UL Listed MH29367. Liquid level gauges which are intended to be used on aboveground storage tanks and monitor the level of petroleum-based flammable or combustible fluids.

Ordering Specifications

Ordering Specifications

Product #	Description	lb.	kg
CARB APPROVED AST EQUIPMENT
200TG-ENG	English Unit Tank Gauge up to 18 ft.	7.75	3.52
200TG-ENG40	English Unit Tank Gauge - 40 ft.	7.75	3.52
200TG-MET	Metric Unit Tank Gauge up to 6 m	7.75	3.52
200TG-MET40	Metric Unit Tank Gauge - 10 m	7.75	3.52

Ancillary Equipment

Product #	Description	lb.	kg
H11421RS	2" NPT Male x Male Nipple	1.5	0.68
CARB APPROVED AST EQUIPMENT
61T-0208	2" Dia. x 8' Long Drop Tube	2.67	1.21
61T-0212	2" Dia. x 12' Long Drop Tube	4.00	1.81
61T-0216	2" Dia. x 16' Long Drop Tube	5.33	2.42

Dimensions

	in.	cm
A	8-1/4	21
B	10-1/4	26
C	9	22.75
D	6-3/4	17.25
E	1-1/2	3.75

Replacement Parts

Replacement Parts

Part #	Description
C05165M	Float
H15325M	Lens
H15267M	Lens Gasket
H14909M	Lid Gasket
